| CPU |
AMD Socket AM2+/AM2：Phenom FX/Phenom X4/Phenom X3/Athlon X2/Athlon/Sempron X2/Sempron |
| Hyper Transport |
5200/2000 MT/s |
| チップセット |
AMD 780G/SB700 |
| メモリ |
DDR2 x4 (1200/1066/800/667MHz) Max16GB |
| オーディオ |
Realtek ALC889A codec High Definition Audio |
| LAN |
Realtek 8111C chip (10/100/1000 Mbit) |
| 拡張スロット |
PCI-Express(x16) x1/PCI-Express(x1) x1/PCI(32bit) x2 |
| ストレージ |
IDEx1/SATA(3Gb/s) x5/eSATAx1 Support RAID 0/1/10/JBOD |
| IEEE 1394 |
T.I. TSB43AB23 chip |
| USB |
Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets connected to the internal USB headers) |
Internal I/O
Connectors |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x floppy disk drive connector
1 x IDE connector
5 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x North Bridge fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In/Out header
1 x IEEE 1394a header
4 x USB 2.0/1.1 headers
1 x parallel port header
1 x serial port header
1 x chassis intrusion header
1 x power LED header |
Back Panel
Connectors |
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x DVI-D port (Note 4)(Note 5)
1 x HDMI port(Note 5)
1 x optical S/PDIF Out connector
1 x eSATA 3Gb/s port
1 x IEEE 1394a port
4 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone) |
| I/O Controller |
ITE IT8718 chip |
| H/W Monitoring |
CPU/System temperature detection
CPU/System fan speed detection
CPU overheating warning
CPU/System fan fail warning
CPU/System fan speed control (Note 6) |
| BIOS |
2 x 8 Mbit flash
Use of licensed AWARD BIOS
Support for DualBIOS
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b |
