| CPU |
Support for Socket AM2+/ AM2 processors: AMD Phenom FX processor/ AMD Phenom X4 processor/ AMD Phenom X3 processor/ AMD Athlon X2 processor/ AMD Athlon processor/ AMD Sempron X2 processor/ AMD Sempron processor |
| Front Side Bus |
5200/2000 MT/s |
| Chipset |
North Bridge: AMD 790GX/South Bridge: AMD SB750 |
| Memory |
1) 4 x 1.8V DDR2 DIMM sockets supporting up to 16 GB of system memory
2) Dual channel memory architecture
3) Support for DDR2 1200 (Note 2)/1066/800 MHz memory modules |
| Integrated Memory |
128MB DDR3 SidePort memory |
| Audio |
Realtek ALC889A codec
High Definition Audio
2/4/5.1/7.1-channel
Support for Dolby Home Theater (Note 3)
Support for S/PDIF In/Out
Support for CD In |
| LAN |
Realtek 8111C chip (10/100/1000 Mbit) |
| Expansion Slots |
1 x PCI Express x16 slot, running at x16 (PCIEX16_1) (Note 4)
1 x PCI Express x16 slot, running at x8 (PCIEX8_1)
(The PCIEX16_1 and PCIEX8_1 slots support ATI Hybrid CrossFireX technology and ATI CrossFireX technology, and conform to PCI Express 2.0 standard.)
3 x PCI Express x1 slots
2 x PCI slots |
| Storage Interface |
South Bridge:
1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
6 x SATA 3Gb/s connectors supporting up to 6 SATA 3Gb/s devices
Support for SATA RAID 0, RAID 1, RAID5, RAID 10 and JBOD
iTE IT8718 chip:
1 x floppy disk drive connector supporting up to 1 floppy disk drive |
| IEEE 1394 |
T.I. TSB43AB23 chip
Up to 3 IEEE 1394a ports (1 on the back panel, 2 via the IEEE 1394a bracket connected to the internal IEEE 1394a header) |
| USB |
Integrated in the South Bridge
Up to 12 USB 2.0/1.1 ports (4 on the back panel, 8 via the USB brackets connected to the internal USB headers) |
Internal I/O
Connectors |
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x floppy disk drive connector
1 x IDE connector
6 x SATA 3Gb/s connectors
1 x CPU fan header
2 x system fan header
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In/Out header
2 x IEEE 1394a header
4 x USB 2.0/1.1 headers
1 x serial port header
1 x chassis intrusion header
1 x power LED header |
Back Panel
Connectors |
1 x PS/2 keyboard port
1 x PS/2 mouse port
1 x D-Sub port
1 x DVI-D port (Note 5)
1 x HDMI port
1 x optical S/PDIF Out connector
1 x IEEE 1394a port
4 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/Side Speaker Out/Line In/Line Out/Microphone) |
| I/O Controller |
ITE IT8718 chip |
| Form Factor |
ATX Form Factor; 30.5cm x 24.4cm |
